Description

PERFORMANCE PROCESSOR

• Intel® WHL-UE i7 for industrial computing
• Intel® WHL-UE i5 for industrial computing

Memory & STORAGE

• Up to 32GB DDR4
• 3 x M.2 256GB/512GB/1TB SSD

AUDIO

• 1 x mic, 1 x audio out

Power

• 65W AC to DC adapter

CONNECTIVITY FRONT INPUT/OUTPUT PORTS

• 1 x USB 3.2 Gen 2
• 2 x RS232
• 1 x audio

Power button

• DC input (10V-60V)

REAR INPUT/OUTPUT PORTS

• 2 x USB 2.0
• 1 x USB 3.2 Gen 2
• 1 x HDMI 1.4
• 1 x DP 1.2
• 2 x GbE LAN
• 2 x RS-232

Choice of one of the following:

Industry card

• (CAN bus + 4DI/4Do + 2 x RS-422/485) or
• 2 x NIC (with 2 GbE onboard, total 4 GbE) or
• 4 x NIC (with 2 GbE onboard, total 6 GbE)

Design

• DIMENSIONS : 179mm x 182.9mm x 72mm (7.04in x 7.2in x 2.83in)
• WEIGHT : 2.6kg/5.7lb
